High Quality High Temperature Clear Round Quartz Glass Plate

FOB Reference Price:Get Latest Price
$1.00 - $100.00 / Pieces | 1 Piece/Pieces (Min. Order)
Shipping:
Support Express · Sea freight · Land freight · Air freight
Report Suspicious Activity
Overview
Quick Details
Type:
Clear Quartz Plate
Application:
Industry
Thickness:
Customized
Shape:
Circular Shape
Place of Origin:
Liaoning, China
Brand Name:
SUCCESS
Model Number:
SUC
Color:
Transparent
Material:
99.99% Pure Quartz
Product Name:
SUCCESS High Quality Small Diameter Quartz Plate
Size:
Customer's Requirement
Package:
Standard Export Package
Surface:
Polished
Work Temperature:
1200C
Name:
Quartz Plate
Keywords:
Quartz Plate
Diameter:
Customized
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month SUCCESS High Quality Small Diameter Quartz Plate
Packaging & Delivery
Packaging Details
Standard Export Package
Port
Dalian
Product Description

The advantage of Quartz Plate

1.High purity :SiO2> 99.99%.
2.Operating Temperature: 1250℃; SoftenTemperature: 1730℃ .
3.Excellent visual and chemical performance:acid-resistance,alkali resistance,Good thermal stability
4.Health care and environmental protection.
5.No air bubble and no air line.
6.Excellent electrical insulator.

Product Name
SUCCESS High Quality Small Diameter Quartz Plate
Material
99.99% Pure Quartz Crystal
Color
Transparent
Size
1.Square quartz wafers:Length 5-1000mm
                                               Width 5-800mm
                                               Thickness 0.5-300mm
2.Round quartz wafers:Diameter 5-800mm
                                              Thickness 0.5-300mm
3.OEM: All different sizes can be done according to customer's demand.
Application
Widely used in electric light source, electrical appliances (electric), semiconductor, Solar, optical communications, military industry, metallurgy, building materials, chemical, machinery, electricity, environmental protection and other.
Physical Property
Property
Value
Property
Value
Density
2.2x103 kg/m3
Dielectric Properties
(20°C and 1 MHz)
Hardness
5.5 - 6.5 Mohs' Scale 570 KHN 100
Constant
3.75
Design Tensile Strength
4.8x107 Pa (N/m2) (7000 psi)
Strength
5x107 V/m
Design Compressive Strength
Greater than 1.1 x 109 Pa (160,000 psi)
Loss Factor
Less than 4x10-4
Bulk Modulus
3.7x1010 Pa (5.3x106 psi)
Dissipation Factor
Less than 1x10-4
Rigidity Modulus
3.1x1010 Pa (4.5x106 psi)
Index of Refraction
1.4585
Young's Modulus
72GPa (10.5x106 psi)
Constringence (Nu)
67.56
Poisson's Ratio
0.17
Velocity of Sound-Shear Wave
3.75x103 m/s
Coefficient of Thermal Expansion
5.5x10 -7 cm/cm·°C (20°C-320°C)
Velocity of Sound/Compression Wave
5.90X103 m/s
Thermal Conductivity(20°)
1.4 W/m·°C
Sonic Attenuation
Less than 11 db/m MHz
Specific Heat(20°)
670 J/kg·°C
Permeability Constants(700°C)
(cm3 mm/cm2 sec cm of Hg)
Softening Point
1683°C
Helium
210x10-10
Annealing Point
1215°C
Hydrogen
21x10-10
Strain Point
1120 °C
Deuterium
17x10-10
Electrical Resistivity
7x107 ohm cm (350°C)
Neon
9.5x10-10
Products Show


Our Company

       Enterprises have a professional management, design, development, production, testing and modern marketing personnel team.We do research by ourselves, and we are the specialized manufacturer with long history in the quartz glass industry.We serve numerous enterprises at home and abroad with our stable product quality,reasonable price and professional after-sales team.

        We produce and export variety of transparent and quartz glass products, mainly including quartz glass tube, quartz glass plate,quartz glass crucible, quartz glass instrument, quartz heating lamp,UV germicidal lamp, quartz rod, different Infrared and Ultraviolet quartz glass and other relation quartz glass products. Especially we have a great achievement on Quartz singing products, Quartz singing products including Quartz crystal singing bowl, Quartz crystal singing forks,Quartz crystal singing pyramid, singing harp and so on.
        We will provide best quality, best service and best price, warmly welcome your visit !

Packing & Delivery


FAQ

Q: Are you trading company or manufacturer ?

A: We are a manufacturer offer any customized service.

Q: How long is your delivery time?

A: Generally it is 2-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample but it doesn't free.

Q: What is your terms of payment ?

A:100% in advance.
If you have another question, pls feel free to contact us as below:
